Essential Items to be Purchase

Square Aluminum Tubes (鋁方管)

• 20x20x2 mm
• 15x15x2 mm
• 40x20x2 mm

304 Socket screw (304 杯頭内六角螺絲)

• M4 screw
  • Most common M4 screw length: 25 – 45mm
• M3 screw
  • Most common M3 screw length: 10 – 30mm
• M5 screw
  • Most common M5 screw length: 10 – 20mm

304 Nuts (304 螺母)

• Nuts (螺母)
  • M3 Nuts
  • M4 Nuts
  • M5 Nuts

• Lock Nuts (防松螺母)
  • M3 Lock Nuts
  • M4 Lock Nuts
  • M5 Lock Nuts

Nuts (螺母)

Lock Nuts (防松螺母)

304 Washer (304螺絲墊片)

• M4*8*0.5 Washer
• M3*6*0.5 Washer
• M5*10*1.0 Washer

Washer (螺絲墊片)

AWG Cables (AWG 電絲)

• 16 AWG red (Most common)
• 16 AWG black (Most common
• 18 AWG red
• 18 AWG black
• 18 AWG yellow
• 12 AWG red (For Max current and battery)
• 12 AWG black (For Max current and battery)

Heat Shrink Tube (熱縮通)

• 4mm red
• 4mm black
• 4mm yellow
• 6mm red (Most Common)
• 6mm black (Most Common)
• 8mm red
• 8mm black

Other sizes and colours depend on usage. Better buy those with high shrinking ratio.

• XT60 male & female w/ cap (XT60 公&乸 带護套) (Keep the Storage!!!)

• MR30 male & female w/ cap (MR30 公&乸 带護套)

• T-shape male & female w/ cap (T型插頭 公&乸 带護套) (Keep the Storage!!!)

• XT30 male & female (XT30 公&乸)

Jumper Wire (杜邦線)

• Male – Male
• Female – Female
• Male – Female

Just keep every sizes and combination in storage. And don’t buy a cheap one.

Tubes (氣管)

• TU0425B-100 (04: 外徑 25: 內徑 B: 黑色 100: 100米長)
• TU0604B-100 (we still have a lot a lot as of 2024)

KQ2H Connectors (直通螺紋快速接頭)

• KQ2H06-01AS
• KQ2H06-02AS
• KQ2H06-M5A
• KQ2H04-M5A
• KQ2H04-01AS
• KQ2H04-02AS

KQ2H Connectors (變徑對插快換接頭)

• KQ2H06-00A (6mm to 6mm)
• KQ2H04-06A (6mm to 4 mm)

KQ2U Connectors (U形三通直徑接頭)

• KQ2U06-00A
• KQ2U04-00A

KQ2T Connectors (T形三通直徑接頭)

• KQ2T06-00A
• KQ2T04-00A

KQ2L Connectors (彎通外螺紋接頭)

• KQ2L06-M5A
• KQ2L06-01AS
• KQ2L06-02AS
• KQ2L04-M5A
• KQ2L04-01AS
• KQ2L04-02AS

KSL Connectors (高速旋轉360度接頭)

• KSL04-M5
• KSL06-M5
• KSL06-01S
• KSL06-02S

KQ2L Connectors (彎通快插快換氣動接頭)

• KQ2L04-00A
• KQ2L06-00A

KQ2C Connectors (接頭單邊管帽堵頭)

• KQ2C04-00A
• KQ2C06-00A

AS1211F Speed Control Valve (節流閥調速閥限入型接頭)

• AS1211F-M5-04A
• AS1211F-M5-05A

AS1002F Speed Control Valve (節流閥)

• AS1002FS-04A
• AS1002FS-06A

VHK3 Mechanical Valve (手動閥)

• VHK3-04F-04F
• VHK3-06F-06F

SY series Solenoid Valve (電磁閥)

• SY3220-5LZE-M5
• SY3420-5LZE-M5
• SY5220-5LZE-01
• SY5420-5LZE-01

Contact CS for specific specifications. More details on selecting Solenoid Valve please read this article (link).

SS5Y Bar Stock Manifold (電磁閥底座氣動匯流板)

• SS5Y3-20-01
  (SS5Y3-20 means the Manifold for SY3000 Series)
  (01 means number of Port)
• SY3000-26-9A (蓋板)
• SY3000 電磁閥底座
• SS5Y5-20-01
  (SS5Y5-20 means the Manifold for SY5000 Series)
  (01 means number of Port)
• SY5000-26-9A (蓋板)
• SY5000 電磁閥底座

Hollow Hex Plug for Manifold (電磁閥底座金屬堵頭)

• 1/8 inch (01S)
• 1/4 inch (02S)

AR Regulator (減壓閥)

• AR20-02BE-B

Bottle Cap with Tube Connector (快插雙接頭瓶蓋)

• Always this same one
